LEX Products

30 kW ECU Distribution Box (CDN)

MEPDIS-R power distribution assembly with protected branch circuits and a 120 V GFCI convenience outlet. See the connector schedule, dimensions and weight below.

Part numberDB100MA-P1021Q-01S3-CDN

Manufacturer, product and reference are included automatically. Add more products before submitting.

View catalogue on Primex

Product specifications

Product family: USMC MEPDIS-R
Enclosure: Molded rubber with HDPE top and bottom
Supply voltage: 208Y/120 V, three-phase
Inputs: 1 × 100 A, three-phase IEC pin-and-sleeve
Distribution outputs: 4 × 60 A and 6 × 30 A three-phase IEC pin-and-sleeve
Dimensions (H × W × D): 19 × 36 × 26 in
Weight: 180 lb
Convenience outlet: 1 × 20 A, 120 V GFCI duplex receptacle
Supply confirmation: Feeder cables, adapters and additional accessories are specified in the Primex quotation.
NSN: 6110-20-011-3700
ECU branch breakers: 60 A (Canadian configuration)
U.S. version: DB100MA-P1021Q-01S3; NSN 6110-01-586-2426; 40 A ECU branch breakers

Final configuration, compatibility, availability and lead time are confirmed in Primex’s quotation.
